`c4d.utils.noise.C4DNoise` ¶

An important technique for generating procedural textures is the use of fractal noise.

class c4d.utils.noise. C4DNoise ¶

C4DNoise.__init__()

C4DNoise.CreateMenuContainer()
C4DNoise.HasOctaves()
C4DNoise.HasCycles()
C4DNoise.HasAbsolute()
C4DNoise.EvaluateSampleOffset()

C4DNoise.InitFbm()
C4DNoise.Noise()
C4DNoise.SNoise()
C4DNoise.Turbulence()
C4DNoise.Fbm()
C4DNoise.RidgedMultifractal()

Members ¶

C4DNoise. __init__ ( [ seed=665 ] ) ¶

Parameters:	seed ( int ) – Noise seed.
Return type:	c4d.utils.noise.C4DNoise
Returns:	A new noise object.

static C4DNoise. CreateMenuContainer ( [ bIncludeNone=False ] ) ¶

Creates a menu container with the different noise options available:

bc = noise.C4DNoise.CreateMenuContainer(False)
for index, name in bc:
  print index, name

Parameters:	bIncludeNone ( bool ) – Include the none option.
Return type:	c4d.BaseContainer
Returns:	Generated noise menu.

static C4DNoise. HasOctaves ( t ) ¶

Checks if a certain noise type supports the octaves parameter.

Parameters:	t ( int ) – Noise type.
Return type:	bool
Returns:	True if octaves is supported, otherwise False .

static C4DNoise. HasCycles ( t ) ¶

Checks if a certain noise type supports the cycles parameter.

Parameters:	t ( int ) – Noise type.
Return type:	bool
Returns:	True if cycles is supported, otherwise False .

static C4DNoise. HasAbsolute ( t ) ¶

Checks if a certain noise type supports the absolute parameter.

Parameters:	t ( int ) – Noise type.
Return type:	bool
Returns:	True if absolute is supported, otherwise False .

static C4DNoise. EvaluateSampleOffset ( type , rOctaves , rDelta ) ¶

Evaluates the sample offset.

Parameters:	type ( int ) – Noise type. rOctaves ( float ) – Number of octaves. rDelta ( float ) – Delta.
Return type:	float
Returns:	The sample offset.

C4DNoise. InitFbm ( lMaxOctaves , rLacunarity , h ) ¶

Initializes fractal brownian motion.

Parameters:	lMaxOctaves ( int ) – The maximum octave. rLacunarity ( float ) – This parameter controls the scale of each successive fractal overlay. h ( float ) – H-Parameter
Return type:	bool
Returns:	Initializes fractal brownian motion

C4DNoise. Noise ( t, two_d, p[, time=0.0][, octaves=4.0][, absolute=False][, sampleRad=0.25][, detailAtt=0.25][, t_repeat=0] ) ¶

Samples a 2D or 3D noise.

Parameters:	t ( int ) – The noise Type: Noise Types Note Please use `InitFbm()` before you use one of the following noise types: NOISE_ZADA, NOISE_DISPL_VORONOI, NOISE_OBER, NOISE_FBM, NOISE_BUYA. two_d ( bool ) – True for 2D Sampling, False for 3D Sampling p ( c4d.Vector ) – Noise coordinate. time ( float ) – Time. octaves ( float ) – Octaves, if supported. See `HasOctaves()` absolute ( bool ) – Absolute value, if supported. See `HasAbsolute()` sampleRad ( float ) – Sample radius. detailAtt ( float ) – Detail attenuation. t_repeat ( int ) – Must be 2^x - 1 , where x = [1..10], i.e. one of 1, 3, 7, 15, 31, 63, 127, 255, 511, and 1023. A noise repeats itself in time every 1024 units. Using a smaller repeat the noise will repeat at an earlier time.
Return type:	float
Returns:	Noise sample.

C4DNoise. SNoise ( p , lRepeat [ , t=0.0 ] ) ¶

Generate a periodic signed noise value.

Parameters:	p ( c4d.Vector ) – Noise coordinate. lRepeat ( int ) – Must be 2^x - 1 , where x = [1..10], i.e. one of 1, 3, 7, 15, 31, 63, 127, 255, 511, and 1023. A noise repeats itself in time every 1024 units. Using a smaller lRepeat the noise will repeat at an earlier time. t ( float ) – The time.
Return type:	float
Returns:	Signed noise value, this is between -1.0 and 1.0.

C4DNoise. Turbulence ( p , rOctaves , bAsolute [ , t=0.0 ] ) ¶

Generate a turbulence value, this is a sum of multiple noises with different frequency.

Parameters:	p ( c4d.Vector ) – Turbulence coordinate rOctaves ( float ) – The number of octaves. bAbsolute ( bool ) – True for absolute values. t ( float ) – The time.
Return type:	float
Returns:	Noise sample.

C4DNoise. Fbm ( p , rOctaves , lRepeat [ , t=0.0 ] ) ¶

Generate a periodic Fractional Brownian Motion value.

Note

Needs the call InitFbm() before.

Warning

The rOctaves value must not exceed the value passed to InitFbm() but can be lower.

Parameters:	p ( c4d.Vector ) – The evaluation point. rOctaves ( float ) – The octaves lRepeat ( int ) – Must be 2^x - 1 , where x = [1..10], i.e. one of 1, 3, 7, 15, 31, 63, 127, 255, 511, and 1023. A noise repeats itself in time every 1024 units. Using a smaller repeat the noise will repeat at an earlier time. t ( float ) – The time
Return type:	float
Returns:	The fbm value.

C4DNoise. RidgedMultifractal ( p , rOctaves , rOffset , rGain , lRepeat [ , t=0 ] ) ¶

Generate a periodic fractal function used for such things as landscapes or mountain ranges.

Note

Needs the call InitFbm() before.

Warning

The rOctaves value must not exceed the value passed to InitFbm() but can be lower.

Parameters:	p ( c4d.Vector ) – The evaluation point. rOctaves ( float ) – The octave. rOffset ( float ) – The zero offset, this controls the multifractality. rGain ( float ) – The amplification of the fractal value. lRepeat ( float ) – Must be 2^x - 1 , where x = [1..10], i.e. one of 1, 3, 7, 15, 31, 63, 127, 255, 511, and 1023. A noise repeats itself in time every 1024 units. Using a smaller lrepeat the noise will repeat at an earlier time. t ( float ) – The time.
Return type:	float
Returns:	The fractal value.

Example ¶

Creates a noise and save it in a bitmap:

import c4d
from c4d.utils.noise import C4DNoise
from c4d import bitmaps
width = 300
height = 300
noisetype = c4d.NOISE_DISPL_TURB
bmp =  bitmaps.BaseBitmap()
bmp.Init(width, height, 24)
# Create and initialize the noise instance
p = C4DNoise(1234)
p.InitFbm(21, 2.1, 0.5)
rw = float(width-1)
rh = float(height-1)
# Iterate through the bitmap and set the noise value per pixel
for x in xrange(width):
  for y in xrange(height):
    r = p.Noise(noisetype, False, c4d.Vector(x/rw, y/rh, 0) * 7.0, octaves=5)
    o = int(255.0*r)
    if o < 0: o = 0
    elif o > 255: o = 255
    bmp[x, y] = (o, o, o)
bitmaps.ShowBitmap(bmp)
